Hollow Shaft Encoders

Hollow Shaft Encoders

6000.00 - 30000.00 INR/Pair

Product Details:

X

Hollow Shaft Encoders Price And Quantity

  • 6000.00 - 30000.00 INR/Pair
  • 10 Pair

Hollow Shaft Encoders Trade Information

  • Mumbai , Maharashtra
  • 100 Pair Per Week
  • 2 Week
  • Yes
  • Within a certain price range free samples are available
  • Export Packaging
  • All India

Product Description

We manufacture and export globally the excellent quality range of Hollow Shaft Encoders. This plate is properly designed and assembled by utilizing finest quality grade of components in accordance with current market standards. These encoders have a fixed housing with rotor wheel which revolves around the shaft and helps in determining speed, positioning, and other motion information. Our clients can easily avail these Hollow Shaft Encoders from us at the best market competitive price range.





Features:



  • High voltage bearing capability

  • Long operational life

  • Heat resistive

Specifications:

  • Through hollow shaft 15 bis 42 mm
  • Outside diameter only 76 mm
  • Easy installation by means of clamping ring front or rear
  • Operating temperature up to 100 C
  • Applications: motors, printing machines, lifts

NUMBER OF PULSES

  • 50 / 100 / 128 / 250 / 256 / 300 / 314 / 360 / 500 / 600 / 720 / 900 / 1000 / 1024 / 1250 / 1500 / 2048 / 2500 / 3072 / 4096 / 5000 / 9000 / 10000
  • Other number of pulses on request

TECHNICAL DATA mechanical

Housing diameter

76 mm

Shaft diameter

15 mm / 16 mm / 18 mm / 20 mm / 24 mm / 25 mm / 27 mm / 28 mm / 30 mm / 32 mm / 38 mm / 40 mm (Hub shaft)

Flange (Mounting of housing)

Tether

Mounting of shaft

Front clamping ring, Rear clamping ring

Protection class shaft input (EN 60529)

IP40 or IP64

Protection class housing (EN 60529)

IP50 (IP65 optional)

Minimum length of mountig shaft clamping ring front

32 mm with 15 ... 30, 35 mm with >30 ... 42

Mimimum length of mounting shaft clamping ring rear

Corresponding to total length of encoder

Axial endplay of mounting shaft (hubshaft)

With stator coupling A (flexible): 2 mm
With 1x stator coupling (torsionally rigid): 0.5 mm
With 2x stator coupling (torsionally rigid): 0.3 mm

Radial runout of mating shaft (hubshaft)

With stator coupling A (flexible): 0.15 mm
With 1x stator coupling (torsionally rigid): 0.3 mm
With 2x stator coupling (torsionally rigid): 0.2 mm

Max. speed

For 15 ... 25 mm at 70 C and IP64: max. 3600 rpm
For >25 ... 42 mm bei 70 C and IP64: max. 1800 rpm
For 15 ... 42 mm at 70 C and IP40: max. 6000 rpm
For 15 ... 42 mm at 100 C always: max. 1800 rpm

Torque

3 ... 10 Ncm (depending on version)

Moment of inertia

Approx. 140 ... 420 gcm (depending on version)

Vibration resistance (DIN EN 60068-2-6)

10 g = 100 m/s (10 ... 2000 Hz)

Shock resistance (DIN EN 60068-2-27)

100 g = 1000 m/s (6 ms)

Operating temperature

-25 C ... +100 C

Storage temperature

-25 C ... +100 C

Material housing

Aluminum

Weight approx.

320 ... 580 g (depending on version)

Connection

Cable, radial
